Beidou II /GPS jammer is an independent, remote control jammer. The interference source can output a variety of standard interference signals at BD2-B1/B2/B3, GPS-L1, GLONASS-L1 frequency points. The jammer is lightweight, compact, flexible and suitable for wireless performance testing and electronic countermeasures applications of various anti-jamming receivers.
· Product features:
· The device can output a variety of standard interference signals of BD2-B1/B2/B3, GPS-L1, GLONASS-L1 frequency points;
· The device can be controlled remotely through serial port and wireless.
· Support power adjustment;
· The maximum output power is not less than 30dBm;
· Optional large capacity lithium battery, can continue to work in the field;
· The output power can be expanded and enhanced (external power amplifier);
· With a host/antenna split structure, a variety of antennas can be flexibly used.
· Application field:
Anti-interference equipment batch field experiment, comparison, acceptance.
· Performance index:
|
Operating Frequency Point |
BDS B1/B2/B3/S , GPS L1/L2/L5 , GLO L1/L2 , GAL E1/E5 , QZSS L1/L2 , SBAS L1 |
|
Point frequency interference |
1-3GHz |
|
Sweep interference |
The starting and ending frequency of frequency sweep can be set (within a 20M bandwidth),
|
|
White noise interference |
Signal center frequency point, bandwidth can be set (2M, 4M, 10M, 20M, 50M)
|
|
Pulse interference |
Pulse width：1us-10s
|
|
Maximum output power |
30±1dBm，External power amplifier extension
|
|
Power adjustment range |
-30~30dBm，Step：1dB |
|
Operating voltage |
12~28VDC/220V AC |
|
Dimensions |
Host:145mm*98mm*63.5mm: Antenna:¢194ⅹ68mm |
